KSB Strainer Germany | Bộ Lọc Y KSB Đức

KSB BOA-S

KSB Strainers

- KSB Strainer to DIN/EN with flanged ends, KSB Strainer to ANSI/ASME with threaded sockets (NPT) or socket weld ends (SW) and KSB Strainer to DIN/EN with flanged ends (FSL) or butt weld ends (FSS).

____________________________________

Technical KSB Strainer

- Body: Nodular cast iron (EN-GJL-250 (5.1301)), Stainless steel, Cast steel A216 WCB, Forged steel A105,

- Cover: Nodular cast iron EN-GJL-250 (5.1301), Cast steel, stainless steel

- Strainer: X 5 CrNi 18 10 (1.4301), stainless steel 304/316

- Connection ends: DIN/EN, ANSI/ASME Flanged ends, Butt / Socket weld ends,  Threaded sockets (NPT)

- Pressure range: 16 bar up to 160 bar

- Temperarure range: 450 °C

- Size: DN15 - DN400

- Origin: KSB Germany

____________________________________

Types of KSB Strainer

KSB Y Strainer BOA-S, KSB Y Strainer BOACHEM-FSA, KSB Y Strainer ECOLINE FYC 150-600, KSB Y Strainer ECOLINE FYF 800, KSB Y Strainer NORI 40 FSL/FSS

KSB Strainer BOA-S

- KSB Strainer BOA-S is strainer to DIN/EN with flanged ends, with standard or fine screen; all nominal sizes with drain plug in the cover. Made of grey cast iron or nodular cast iron.

KSB Y Strainer BOACHEM-FSA

- KSB Y Strainer BOACHEM-FSA is strainer to DIN/EN with flanged ends, body made of stainless steel, with standard or fine screen; all nominal sizes with drain plug in the cover.

KSB Y Strainer ECOLINE FYC 150-600

- KSB Y Strainer ECOLINE FYC 150-600 is strainer to ANSI/ASME with flanged ends, Y-pattern, bolted cover, cast steel A216 WCB, screen made of stainless steel 304, mesh width 1.5 mm.

KSB Y Strainer ECOLINE FYF 800

- KSB Y Strainer ECOLINE FYF 800 is Strainer to ANSI/ASME with threaded sockets (NPT) or socket weld ends (SW), Y-pattern, with bolted cover, forged steel A105, screen made of stainless steel 304. Mesh width 0.8 to 0.9 mm.

KSB Y Strainer NORI 40 FSL/FSS

- KSB Y Strainer NORI 40 FSL/FSS is Strainer to DIN/EN with flanged ends (FSL) or butt weld ends (FSS), made of cast steel, with standard or fine screen; all nominal sizes with drain plug in the cover, optional magnetic insert.

____________________________________

Applications of KSB Y Strainer

- Water : From extraction and transport right through to treatment, KSB offers pumps, valves and services for water and waste water applications.

- General industry : Almost no industrial process would be possible without pumps and valves. We accompany our industrial customers from the initial planning stage through to operation and the end of the life cycle of our products.

- Building services : Whether in water supply or drainage, air conditioning or fire protection, KSB pumps and valves are employed in all types of buildings, such as offices, residential houses, hospitals or swimming pools.

- Petrochemicals and chemicals : High temperatures and pressures, flammable fluids – chemical pumps and valves have to withstand extreme conditions. By providing innovative designs and comprehensive service, KSB ensures reliable production.

- Energy : No matter whether the energy comes from the sun, wind, fossil fuels, geothermal heat or nuclear power - KSB offers efficient, safe and reliable solutions for power generating companies around the globe.

- Mining : Minerals are the raw material used as the basis for many products used in our daily life. KSB’s line of GIW® pumps are used to move slurry, a mixture of mined material suspended in water, across long distances or within a processing plant.

____________________________________

Báo Giá Lọc Y KSB VINDEC

____________________________________

Mua Lọc Y VINDEC

- VINDEC là địa chỉ phân phối Van Lọc Y uy tín tại Việt nam có thể làm hài lòng khách hàng với năng lực đội ngũ nhân viên có kỹ thuật trình độ kỹ thuật cao, được đào tạo chuyên nghiệp bài bản của hãng.

- Quý khách hàng có thể tìm kiếm hoặc Download về máy Catalogue sản phẩm vật liệu làm kín của hãng tại Website của chúng tôi với thông số kỹ thuật rõ ràng chính xác nhất của hãng: Lọc Y

- Thêm vào đó, VINDEC chúng tôi có Kho Hàng tại Hồ Chí Minh và có Kho Hàng + Xưởng Sản Xuất với diện tích trên 2.000m2 tại Hà Nội.

- VINDEC với năng lực và kinh nghiệm gần 20 năm cùng với đội ngũ kỹ sư giầu chuyên môn, chúng tôi có thể đáp ứng được các dự án lớn về hàng Van Công Nghiệp chúng tôi luôn đồng hành cùng phát triển.
