Valqua Group

- Since our founding in 1927, we at the VALQUA Group have worked tirelessly to offer our customers both the “value” and “quality” that forms our name, and have supported and contributed to the development of the Japanese economy as a pioneer of industrial seal products and processed fluororesin products.

- At present, the VALQUA Group is expanding its business in 3 major product areas: the “Seal Products Business”, which involves the development of seal materials for piping and equipment used in various industries, such as petroleum refining, petrochemistry, ironmaking, energy plants, automobiles, hydraulic-pneumatic equipment, construction equipment,and semiconductor manufacturing equipment; the “High-performance Plastics Products Business”, which involves products predominantly utilizing fluorocarbon resin with a variety of different functions; and “Silicon Wafer Reclaim and Other Businesses” that have a lot of growth potential and will help decrease our impact on the environment.

- As business models have changed significantly across the world over the past few years as a result of evolutions in Al and loT, we at the VALQUA Group have been developing products using our advanced proprietary technologies, and working toward reforms that will allow us to fully leverage our Group's strengths through collaborations with businesses that have revolutionary technologies, service development, and know-how, thereby contributing to the resolution of social issues in various fields, and the creation of a sustainable society.

- As the VALQUA Group heads toward its 100th anniversary in 2027, and looks further beyond that milestone , we are striving to become a "challenging company that challenges the future and the unknown," will create new forms of added value, realize sound and sustainable growth, and meet the expectations of our customers.

Valqua Products

• Seal Products

- Soft Gasket: High Performance Non-Asbestos Sheet Gasket, Compressed Non-Asbestos Fiber Sheet Gasket, Fluolrocarbon Resin Sheet Gasket, CORDSEAL<Soft>, Fluolrocarbon Resin Envelope Gasket, Expanded Graphite Sheet Gasket, Ruber Coated Fabric Gasket, Ruber Sheet Gasket

- Metallic / Semi-Metallic Gasket: Spiral Wound Gasket, Metal Jacketed Gasket, Metal Serrated and Flat Gasket, Ring Joint Gasket, Metal C-Ring Gasket with Spring, Metal Hollow O-ring Gasket

- Molded Packing: O-ring, X-ring, T-ring, D-ring, V-packing, U-packing, Dust Seal, Various Molded Packing, Oil Seal, Diaphragm, Other Seals, Molded Products

- Gland Packing: Carbon Fiber Based, VALFLON Based, Special Fiber Based, Metal Based, Flexile Graphite Based, Inorganic Fiber Based, Flexible Graphite Based General Use Grade

- Metallic Bellows: Expansion Joint(Metallic Bellows), Supplement product for seal, Gasket Paste, Gasket Cutter, Packing Tool

- Other Seals: Oil Sheet, Other Gasket, Alliance Products

• Resin Products

- Material and Block: Sleeve, Sheet and Plate, Round Bar, Containing Filler, CORDSEAL<Soft>, Soft Sheet

- Film / Tape / Sheet: Film, Reinforced Film, Surface Treated Film, Unbaked Tape, Adhesive Tape, Cross-linked PTFE Tape, PI Film Laminated Product. Glass Cloth (Fabric) Impregnated with PTFE, Fabric Adhesive.

- Tube: Corrugated Tube

- Processed Products and Molded Products: Bellows, Diaphragm, Bearing, Sealing Material, Back-up Ring, Washing Nozzle, Processed Products, VALFLON PFA Bolt and Nut.

- Lining Pipe and Tank Parts: Lining Steel Pipe, Flexible Horse, Lining Bellows Insertion Pipe, Lining Tank

- Substrate: PTFE Substrate (For HF Wave/MM Wave), Prepreg (For HF Wave/MM Wave)

• Heat Insulation Material

- Textile Products: Flame-Resistant Cabonized Fiber Textile, Heat-Resistant Glass Fiber Textile

- Slip Material: Bearing, Luricant

• Other Products

- Piping: Fluorocarbon resin Vessel, Valve, Expansion Joint(Metallic Bellows), Expansion Joint(Non Metallic Bellows), Mechanical Seal.

- Device / Equipment: VALFLON Lined Device / Equipment

VALQUA - Spiral Wound Gasket

Gioăng Kim Loại VALQUA | Spiral Wound Gasket, gioăng chì thép xoắn chịu nhiệt hơi nóng, áp lực cao làm kín mặt bích đường ống và van công nghiệp

Spiral Wound Gaskets of VALQUA

• BLACKTIGHT - VALQUA

- VALQUA 6590 : BLACKTIGHT (Basic Design)

- VALQUA 6590VC : BLACKTIGHT for Cryogenic Application (Basic Design). This gasket for cryogenic applications has a structure that offers even better flexibility than the 6590 series, for excellent sealability at even low surface pressures.

- VALQUA 6591 : BLACKTIGHT (with Outer Ring)

- VALQUA 6591VC : BLACKTIGHT for Cryogenic Application (with Outer Ring). This gasket for cryogenic applications (with outer ring) has a structure that offers even better flexibility than the 6590 series, for excellent sealability at even low surface pressures.

- VALQUA 6592 : BLACKTIGHT (with Inner Ring)

- VALQUA 6592VC : BLACKTIGHT for Cryogenic Application (with Inner Ring). This gasket for cryogenic applications (with inner ring) has a structure that offers even better flexibility than the 6590 series, for excellent sealability at even low surface pressures.

- VALQUA 6596 : BLACKTIGHT (with Inner/Outer Ring)

- VALQUA 6596VC : BLACKTIGHT for Cryogenic Application (with Inner/Outer Ring). This gasket for cryogenic applications (with inner/outer ring) has a structure that offers even better flexibility than the 6590 series, for excellent sealability at even low surface pressures.

• WHITETIGHT - VALQUA

- VALQUA 7590 : WHITETIGHT (Basic Design)

- VALQUA 7591 : WHITETIGHT (with Outer Ring)

- VALQUA 7592 : WHITETIGHT (with Inner Ring)

- VALQUA 7596 : WHITETIGHT (with Inner/Outer Ring)

• CLEANTIGHT - VALQUA

- VALQUA 8590 : CLEANTIGHT (Basic Design)

- VALQUA 8591 : CLEANTIGHT (with Outer Ring)

- VALQUA 8592 : CLEANTIGHT (with Inner Ring)

8596 : CLEANTIGHT (with Inner/Outer Ring)

• NONASUPER - VALQUA

- VALQUA 8590TN : This product is formed by winding metal strips around the periphery of a basic design non-asbestos spiral wound gasket.

• MICA FILER - VALQUA

- VALQUA M596L : Spiral Wound Gaskets Made of Lined Mica Filler (with Inner/Outer Ring). This type adds an inner/outer ring to No. M590L.

- VALQUA M596 : Spiral Wound Gaskets Made of Mica Filler (with Inner/Outer Ring). This type adds an inner/outer ring to No. M590.

- VALQUA M592L : Spiral Wound Gaskets Made of Lined Mica Filler (with Inner Ring). This type adds an inner ring to No. M590L.

- VALQUA M592 : Spiral Wound Gaskets Made of Mica Filler (with Inner Ring). This type adds an inner ring to No. M590.

- VALQUA M591L : Spiral Wound Gaskets Made of Lined Mica Filler (with Outer Ring). This type adds an outer ring to No. M590L.

- VALQUA M591 : Spiral Wound Gaskets Made of Mica Filler (with Outer Ring). This type adds an outer ring to No. M590.

- VALQUA M590L : Spiral Wound Gaskets Made of Lined Mica Filler (Basic Design). This spiral wound gasket features an M590 spiral wound core wrapped in VALQUAFOIL tape.

- VALQUA M590 : Spiral Wound Gaskets Made of Mica Filler (Basic Design). This spiral wound gasket uses a clothless mica filler created using a special manufacturing process.

VALQUA Gland Packing

- VALQUA Gland packing is a general term to mean those types of packing which are inserted in a stuffing box and apply tightness force to seal a fluid by means of compression, and it is also called simple compression packing.

- Thanks to it is simple construction and reasonable prices, gland packing has long been widely in use as a shaft sealing material for different types of equipment.

Gland Packings of VALQUA

• Carbon Fiber Based

- VALQUA 6201 : Carbonized Fiber Coil Packing

- VALQUA 6232 : Carbon Fiber Coil Packing

- VALQUA 6234 : PTFE-Coated Carbonized Fiber

- VALQUA 6262 : Carbon Fiber Coil Packing

- VALQUA 6267 : Carbon Fiber Coil Packing

- VALQUA 6345 : Carbon Fiber Coil Packing

- VALQUA 6399 : Carbon Fiber Coil Packing

- VALQUA 6399H : Carbon Fiber Ring Packing

- VALQUA 6399L : Carbon Fiber Coil Packing

• VALFLON Based

- VALQUA 7202 : PTFE Mixed Graphite Packing

- VALQUA 7202E : Graphite Mixed VALFLON Fiber Coil Packing

- VALQUA 7202W : Filler Mixed VALFLON Fiber Coil Packing

- VALQUA 7203 : PTFE Mixed Graphite Packing

- VALQUA 7232 : PTFE Packing

- VALQUA 7233 : PTFE Packing

- VALQUA 7262 : PTFE Packing

• Special Fiber Based

- VALQUA 8132 : Aramid/Inorganic Coil Packing

- VALQUA 8133 : Aramid/Inorganic Coil Packing

- VALQUA 8133L : Aramid/Inorganic Coil Packing

- VALQUA 8137 : Aramid/Inorganic Coil Packing

- VALQUA 8201 : Aramid Coil Packing

- VALQUA 8201NL : Aramid Coil Packing

- VALQUA 8301 : Organic fiber coil packing

• Metal Based

- VALQUA 1110 : Aluminum Foil Spiral Packing

• Flexile Graphite Based

- VALQUA VF-10 : VALQUAFOIL Ring Packing

- VALQUA VF-20 : VF Braid Packing

- VALQUA VF-20L : VF Braid Packing

- VALQUA VF-20LF : VF Braid Packing

- VALQUA VF-22 : VF Braid Packing

- VALQUA VFC-25 : Carbon Fiber Reinforced VF Braid Packing

- VALQUA VFT-22 : PTFE-cladded VF Braid Packing

- VALQUA VFX-15 : VF Braid Reinforced by Metal Wire

• Inorganic Fiber Based

- VALQUA N340G : High Temperature Inorganic Fiber Braid Packing

- VALQUA N340M : High Temperature Inorganic Fiber Braid Packing

• Flexible Graphite Based General Use Grade

- VALQUA N1271 : Graphite Grade Packing

- VALQUA N1290 : Graphite Grade Packing

- VALQUA N133 : Graphite Grade Packing

VALQUA Non Asbestos Fiber Sheet - VALQUA

• High Performance Non Asbestos Gasket

__________________________________________

• Compressed Non Asbestos Fiber Gasket

__________________________________________

Types of Non Asbestos Sheets - VALQUA

• VALQUA 6602 Non Asbestos Gasket

__________________________________________

• VALQUA  VGS02 Non Asbestos Gasket

__________________________________________

• VALQUA 6500 Non Asbestos Gasket

Non-asbestos fiber mixed with heat/chemical resisting rubber binder, then rolled and vulcanized

__________________________________________

• VALQUA 6500AC Non Asbestos Gasket

Version of No.6500 with anticorrosion treatment and antistick treatment.

__________________________________________

• VALQUA 6502 Non Asbestos Gasket

High heat and steam resistant Non-asbestos joint sheet that inhibits hardening caused by heat deterioration, by blending highly heat resistant, special rubber binder.

__________________________________________

• VALQUA  6503 Non Asbestos Gasket

Since black components are removed in the Compressed Fiber Sheet, these are suitable gaskets to be used for applications where inclusion of black foreign substances into the fluid should be avoided.

__________________________________________

• VALQUA 6503AC Non Asbestos Gasket

Version of No.6503 with anticorrosion treatment and antistick treatment.

__________________________________________

• VALQUA GF300 Non Asbestos Gasket

Highly heat and chemical resistant Non-asbestos sheet mainly composed of graphite and PTFE that excels in thermal and chemical resistance.

__________________________________________

• VALQUA No. MF300 Non Asbestos Gasket

This gasket offers the same high temperature, long-term stability of GF300, but is white and offers improved chemical resistance, allowing it to be used in a wider variety of applications.

__________________________________________

• VALQUA SF300 Non Asbestos Gasket

Like GF300, this product offers excellent heat-resisting properties, chemical resistance, handling, and flexibility. This white sheet gasket contains no black material.

__________________________________________

• VALQUA UF300 Non Asbestos Gasket

This product possesses high-temperature reliability equal to that of other high-performance sheet gaskets (GF300, for example), offering both chemical resistance and high-temperature characteristics.
