VITON Rubber Gasket Sheet

VITON (FKM) RUBBER GASKET SHEET

Viton® rubber sheeting is a high specification fluoroelastomer that is suitable for demanding environments where elevated temperatures and chemicals are present.

Viton® is able to retain its physical and mechanical properties, such as flexibility and fluid resistance, in situations where lesser specification elastomers begin to swell and break down.

It displays excellent resistance to acids, oils and petroleum based products, making it a popular gasket and seal choice in the automotive, aerospace, oil and gas, and chemical processing industries.

TECHNICAL DATA

Specific gravity: 1.8 g/cm3

Hardness: 70+/-5 shore A

Tensile strength: Mpa 8

Pressure Max. (bar): 10 Bar

Color: Black

Shore Hardness: 75° ± 5° (type A), 70° ± 5° (type B).

Temperature: -20°C up to +275°C (type A), -30°C up to +300°C (type B)

Outstanding resistance to acid, oil and petroleum based fluids. Excellent ozone resistance.

Trade Names: Viton® sheet, Fluorel® sheet, Technoflon® sheet, Dai-El® sheet

Size: DN 15, 20, 25, 32, 40, 50, 65, 80, 100, 125, 150, 200, 250, 300, 350, 400, 450, 500

Thickness: 1, 1.5, 2, 3, 4, 5, 7, 8, 10, 12, 15, 20(mm)

Width x Length : 1000 x 10.000mm

APPLICATIONS

Ozone: Excellent

Dilute Acids & Bases: Excellent

Concentrated Acids & Bases: Excellent

Oils: Very Good

Solvents: Very Good
