Virgin PTFE Rod


Virgin PTFE Rod - Nhựa PTFE

- Colour: White
- Density: 2.1 to 2.3 g/cm³
- Tensile Strength: 15 MPa
- Temperature range: -180 ℃ to +260 ℃
- Diameter: Ø4 mm to  Ø500 mm

Virgin PTFE Rod

- Virgin PTFE Rod is goods manufactured with 100% virgin PTFE resin. PTFE rod has two types, extruded PTFE rod and moulded PTFE rod.

- The diameter from 4 to 250mm is extruded PTFE rod and the diameter of moulded PTFE rod is 300 to 500mm.

Technical Virgin PTFE Rod

- Colour: White

- Density: 2.1 to 2.3 g/cm³

- Tensile Strength: 15 MPa

- Elongation at Break: 150%

- Temperature range: -180℃ to +260℃

- Melting Point: 327℃

- Dielectric Strength: 10 Kv/mm

Application of Virgin PTFE Rod

- PTFE rod has the characteristics of high chemical resistance,high insulation,non-stick, low friction and long life.It is used by machine parts such as, connectors, terminals and other electrical parts.

Diameter of Virgin PTFE Rod VINDEC

- Virgin PTFE rod Ø6 mm

- Virgin PTFE rod Ø8 mm

- Virgin PTFE rod Ø10 mm

- Virgin PTFE rod Ø15 mm

- Virgin PTFE rod Ø20 mm

- Virgin PTFE rod Ø30 mm

- Virgin PTFE rod Ø40 mm

- Virgin PTFE rod Ø50 mm

- Virgin PTFE rod Ø60 mm

- Virgin PTFE rod Ø70 mm

- Virgin PTFE rods Ø80 mm

- Virgin PTFE rod Ø90 mm

- Virgin PTFE rod Ø100 mm

- Virgin PTFE rod Ø120 mm

- Virgin PTFE rod Ø150 mm

- Virgin PTFE rod Ø200 mm

- Virgin PTFE rod Ø250 mm

- Virgin PTFE rod Ø300 mm

- Virgin PTFE rod Ø350 mm
