FEROLITE NAM 39

Ferolite NAM 39 - Non Asbestos Gasket Jointing Sheet

Description

- Material Composition (Type of fibres): Cellulose Fibre, Mineral Fibre & Organic Fibre, and Binders with NBR rubber.

Technical Data

- Density: 1.70 - 2.00 (g/cm³)

- Max.Peak Temp: +250°C

- Max. Continuous Temp: +180°C

- Max.Continuous Temp.with steam: +120°C

- Max. Operating Pressure: 50 bar (Kgf/cm2)

- Size: 1500 x 1500mm, 1500 x 2450mm, 3000 x 3000mm

- Thickness: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0mm

- Origin: India

- Brand: FEROLITE

- Distributor: VINDEC

Applications:

- Water/Oil resistant gasket material for light to medium loading. Suitable for low operating pressure, e.g. transformers, compressors and also used for easily deformable components with low surface pressure  like valve covers and pans in internal combustion engines.
