FEROLITE - NAM 32 STEEL

Ferolite NAM 32 STEEL - Non Asbestos Gasket Jointing Sheet

Description

- Material Composition (Type of fibres): Aramid Fiber, Mineral Fiber with metal gauge centre, and Binders with NBR rubber.

Technical Data

- Density: 1.70 - 2.00 (g/cm³)

- Max.Peak Temp: +500°C

- Max. Continuous Temp: +270°C

- Max.Continuous Temp.with steam: +240°C

- Max. Operating Pressure: 150 bar (Kgf/cm2)

- Size: 1500 x 1500mm, 1500 x 2450mm, 3000 x 3000mm

- Thickness: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 4.0, 5.0mm

- Origin: India

- Brand: FEROLITE

- Distributor: VINDEC

Applications:

- Suitable for high performance,oil resistant gasket material with excellent thermal, chemical & mechanical properties. Suitable for compressors, pipelines, transmission, gas meters and internal combustion engines, pipe unions & pumps etc.
