TEADIT - NA 1002EU

Compressed Aramid Fibers Sheet NA 1002EU

Tests & Approvals

- ABS - TEADIT NA 1002EU

- BAM - TEADIT NA 1002EU

- TA-Luft - TEADIT NA 1002EU

- DVGW - TEADIT NA 1002EU

- DVGW HTB - TEADIT NA 1002EU

- WRAS - TEADIT NA 1002EU

- KTW - TEADIT NA 1002EU

- Blow out - TEADIT NA 1002EU

- Flame Resistance Test – TEADIT NA 1002EU

Description

- TEADIT style NA-1002EU is a high-end compressed non asbestos jointing-sheet material made of aramid fibers and bonded with nitrile (NBR) rubber.

- The material has excellent mechanical, temperature and chemical properties. It is being manufactured by means of a hot calender process.

- TEADIT maintains a quality management system that is certified according to DIN EN ISO 9001.

Applications

- TEADIT style NA-1002 is indicated for sealing petroleum derivatives, water, saturated steam, gases and chemical products in general. Exceptional performance in connection with gas.

Technical Data

- Temperature Range (ºC)    Continuous Service: 260 to Peak Service: 400

- Pressure (bar)    Continuous Service: 80 to Peak Service: 110

- Color: Green

Dimension

- Thickness: 0.5, 1, 1.5, 2, 3, 4, 5 mm

- Dimension: 1500 mm x 1600 mm hoặc 1500 mm x 3200 mm
