TEADIT NA-1005

Compressed Aramid Fibers Sheet NA 1005 TEADIT

- TEADIT style NA-1005 is a compressed non-asbestos jointing sheet material produced from a blend of aramid and other synthetic fibers bonded with Nitrile Rubber (NBR). NA-1005 is a general purpose material with very good mechanical, temperature and chemical properties. It is being manufactured by means of a hot calender process. TEADIT maintains a quality management system that is certified according to DIN EN ISO 9001.

- TEADIT style NA-1005M is a compressed non-asbestos jointing sheet material produced from a blend of aramid and other synthetic fibers bonded with Nitrile Rubber (NBR) and with steel wire inserted. NA-1005M is a general purpose material with very good mechanical, temperature and chemical properties. It is being manufactured by means of a hot calender process. TEADIT maintains a quality management system that is certified according to DIN EN ISO 9001.

Applications NA 1005 TEADIT

- TEADIT style NA-1005 is indicated for air, brine, water, low pressure steam, organic and weak inorganic acids, diluted and concentrated alkalis, petroleum derivatives, synthetic and vegetable oils, aliphatic and chlorinated solvents, refrigerants, gases and chemical products in general.

Technical Data NA 1005 TEADIT

- Temperature Range (ºC) Continuous Service: 240 to Peak Service: 400

- Pressure (bar) Continuous Service: 50 to Peak Service: 110

- Color: Blue

Tests & Approvals NA 1005 TEADIT

- Germanischer Lloyd, WRAS, ABS
- ABS Product Type Approval - NA1005
- WRAS_NA1005

Dimension NA 1005 TEADIT

- Thickness: 0.5, 1, 1.5, 2, 3, 4, 5 mm

- Dimension: 1500 mm x 1600 mm hoặc 1500 mm x 3200 mm

- Model. NA-1005: 1500 x 1600 x 0.5mm = 2,5Kg

- Model. NA-1005: 1500 x 1600 x 1mm = 4,5Kg

- Model. NA-1005: 1500 x 1600 x 1.5mm = 7Kg
